Flexible and customized to meet different customer needs and differentiate the needs of rapid technology innovation, product of every process is subject to stringent inspection and testing. In order to ensure that the product is of high reliability and durability, Greenman has always insisted on using high quality raw materials and components.
| BC330 | BC430 | LY35H | LY430MI | |
|---|---|---|---|---|
| Engine | 1E36F-2 Single Cylinder, 2-Stroke, Air Cooled | 1E40F-5 Single Cylinder, 2-Stroke, Air Cooled | Honda GX35T-SDL 4-Stroke, Air Cooled | Mitsubishi TUE43FD 2-Stroke Petrol Engine |
| Output Power | 1.5hp (1.1kW) @ 7000rpm | 2hp (1.5kW) @ 7000rpm | 1.3hp (0.95kW) @ 7000rpm | 1.5hp (1.1kW) @ 7500rpm |
| Output Torque | 1.8Nm @ 6000rpm | 2.4Nm @ 6000rpm | 1.3Nm @ 5500rpm | 1.66Nm @ 6000rpm |
| Displacement | 32.5cc | 42.7cc | 35.8cc | 42.7cc |
| Start | Recoil Start, Primer Bulb for Easy Starting | Recoil Start, Primer Bulb for Easy Starting | Recoil Start, Primer Bulb for Easy Starting | Recoil Start, Primer Bulb for Easy Starting |
| Ignition | CDI | CDI | TCI | Contactless Magnetic Electric Ignition CDI |
| Reduction Ratio | 1:1.33 | 1:1.33 | 1:1.33 | — |
| Fuel Tank Capacity | 0.85L | 1L | 0.63L | 0.9L |
| Lubricating Oil Capacity | — | — | 0.1L | — |
| 2-Stroke Mixture | 25:1 | 25:1 | — | 50:1 |
| Fuel Consumption | 0.7L/h | 0.8L/h | 0.71L/h | 0.8L/h |
| Carburetor Brand | Walbro | Walbro | Walbro | Walbro |
| Spark Plug Brand | Champion | Champion | NGK | Champion |
| Working Pipe | Aluminum, ⌀28mm, 2mm Thickness, 1500mm Length | Aluminum, ⌀28mm, 2mm Thickness, 1500mm Length | Aluminum, ⌀28mm, 2mm Thickness, 1500mm Length | Aluminum, ⌀28mm, 2mm Thickness, 1500mm Length |
| Cutting Head | Nylon (Optional Blades – Bar, 3T, 80T) | Nylon (Optional Blades – Bar, 3T, 80T) | Nylon (Optional Blades – Bar, 3T, 40T, 80T) | Nylon (Optional Blades – Bar, 3T, 40T, 80T) |
