Agricare Corporation

Green Park Gang Mower

Green Park Turfcare Gang Mower - Tractor Driven is a turfcare gang mower ideally suited to mow first cut and second cut of fairways. Available in 3 Unit - GPWM03 and 5 Unit - GPWM05 variants.

Tractor pulled gang mower with steel construction
Special rubber turf tyre type for fairways
Adjustable cutting height from ¾ inch to 4 inches

₹ 407,550

Sale Buy Now

Shipping calculated at checkout.

Variants 3 Unit - GPWM-03 5 Unit - GPWM-05

Product variants

Only 1 units left

Quantity

Request a Quote

Description
Features
Specifications
Application

Description

Green Park Turfcare Gang Mower is a tractor-driven gang mower designed for mowing the first cut and second cut of fairways. The mower is tractor pulled and has a steel constructed frame with properly heat treated construction.

The GPWM03 is available as a 3-unit gang mower while the GPWM05 is a 5-unit gang mower. Both variants feature a cutter reel with 6 blades made from high carbon steel and fully tempered construction. The rear roller runs on bearings on both sides and the mower uses special rubber turf tyres for fairways.

Categories: Products, Tractor-driven Mower

Tags: Agricare Implements, Agricultural Machinery, Gang Mower, Golf Course Mower, Grass Cutter, Green Park, Lawn Mower Attachment, Reel Mower, Sports Field Mower, Tractor Driven Mower, Turf Management

Features

Tractor pulled gang mower construction
Steel construction with properly heat treated steel
Heavy duty hardened steel gears in the transmission
Easy to engage and disengage transmission from the cutter reel
Special steel cutter reel with 6 blades of high carbon steel and fully tempered construction
Rear shock absorber provided to ensure the gang mower units hug the ground
Rear roller running on bearings on both sides with special rubber turf tyres for fairways

Technical Specification

Parameter	Specification
Models / Variants	GPWM03 – 3 Unit; GPWM05 – 5 Unit
Power	Tractor Pulled
Construction	Steel constructed with properly heat treated
Transmission	GPWM03: Heavy duty hardened steel gears with bearings. GPWM05: Heavy duty hardened steel gears.
Clutch	Easy to engage and disengage transmission from Cutter Reel.
Cutter Reel	Special steel cutting reel having 6 blades of high carbon steel and fully tempered.
Bottom Blade	Special steel having high carbon content and fully tempered.
Shock Absorber	GPWM03: Rear shock absorbers. GPWM05: Rear shock absorber provided to ensure that Gang Mower units hug the ground all times.
Roller Weight	25 kg
Draw Bar Pull in Kg	Initial pull 300 kg, in work 150 kg
Acres Cut Per Hour	GPWM03: 8 km/hr – 3, 10 km/hr – 4.2, 16 km/hr – 6. GPWM05: 8 km/hr – 4.5, 10 km/hr – 6.3, 16 km/hr – 9
Height of Cut	GPWM03: 5 positions adjustable from ¾ inch to 4 inches. GPWM05: Adjustable from ¾ inch to 4 inches.
Cutting Width	GPWM03: 1 unit 76 cm, 3 units 2.10 m. GPWM05: 10.5 ft (3.15 meter)
Rear Roller	Running on bearing on both sides.
Wheels	Special rubber turf tyre type for fairways.
Warranty	One-year limited warranty. Refer to Operator’s Manual for further details.

Application

Used as a turfcare gang mower for fairways
Ideally suited to mow the first cut and second cut of fairways
Tractor pulled operation
GPWM03: 3-unit gang mower with 5-position adjustable cutting height from ¾ inch to 4 inches
GPWM05: 5-unit gang mower with adjustable cutting height from ¾ inch to 4 inches
GPWM03 cutting width: 1 unit 76 cm and 3 units 2.10 m
GPWM05 cutting width: 10.5 ft (3.15 meter)
GPWM03 acres cut per hour: 8 km/hr – 3 acres, 10 km/hr – 4.2 acres and 16 km/hr – 6 acres
GPWM05 acres cut per hour: 8 km/hr – 4.5 acres, 10 km/hr – 6.3 acres and 16 km/hr – 9 acres
