Description
-
Features
-
Specifications
-
Application
Greenman Golf Cart is a high quality product with
- Streamline Look
- KDS DC Traction Motor
- Curtis Controller
- High Strength
- Aluminum Alloy Frame
- Mcpherson Independent Suspension
- Color Registers Coating
- Trojan And US Batteries From USA
- Headlights & Taillights
Categories: Golf Car,
Turf Machinery
Specification | G20 | G20M | G40 | S120 |
---|---|---|---|---|
Drive Motor | KDS XP-2067 DC48V Sepex Power: 3700W | KDS ZQS-3.8B-TI-EJI DC48V Sepex Power: 3800W | KDS XP-2067 DC48V Sepex Power: 3700W | KDS XP-2067 DC48V Sepex Power: 3700W |
Maximum Speed | Forward: 22km/h; Reverse: 9km/h | Forward: 22km/h; Reverse: 9km/h | Forward: 22km/h; Reverse: 9km/h | Forward: 22km/h; Reverse: 9km/h |
Grade Ability | 40% (=22°) | 40% (=22°) | 40% (=22°) | 40% (=22°) |
Turning Radius | ≤3m | ≤3m | ≤3m | ≤3m |
Payload | 360kg | 360kg | 360kg | 360kg |
Weight (Incl. Battery) | 410kg | 410kg | 475kg | 490kg |
Wheelbase | 1650mm | 1650mm | 1650mm | 1650mm |
Track | Front tire: 870mm; Rear tire: 960mm | Front tire: 870mm; Rear tire: 960mm | Front tire: 870mm; Rear tire: 960mm | Front tire: 870mm; Rear tire: 960mm |
Suspension | Front: Macpherson independent Rear: Leaf spring + hydraulic shock absorbers | Front: Macpherson independent Rear: Leaf spring + hydraulic shock absorbers | Front: Macpherson independent Rear: Leaf spring + hydraulic shock absorbers | Front: Macpherson independent Rear: Leaf spring + hydraulic shock absorbers |
Brakes | Integrated parking and braking system | Integrated parking and braking system, Electric Parking | Integrated parking and braking system | Integrated parking and braking system |
Frame | High strength aluminium alloy chassis | High strength aluminium alloy chassis | High strength aluminium alloy chassis | High strength aluminium alloy chassis |
Tire | 18×8.5-8 (4 ply); ≤22psi | 18×8.5-8 (4 ply); ≤22psi | 18×8.5-8 (4 ply); ≤22psi | 18×8.5-8 (4 ply); ≤22psi |
Battery | Trojan/US | Trojan/US | Trojan/US | Trojan/US |
Controller | Curtis 1266, 48V/275A | Curtis 1268, 48V/400A | Curtis 1266, 48V/275A | Curtis 1266, 48V/275A |
